Comments on Dense Bricks Data:
These products are sintered refractory dense bricks manufactured by dry processing method and firing in high temperature kilns.Since these products are manufactured from mixture of differebt raw materials,the properties are subject to variartions as the raw materials themselves,may vary.
Nature of Bond:
The nature of bond may be ceramic,Phosphate or chemical in nature.Where several bonds are used together,the bond is designed according to the nature of those bonds which play the dominant role in the fired product.
Shaping:
All the values mentioned in the data sheet related to standard bricks only,manufactured by plastic moulding method.
Raw Material Base:
This is the essential raw material conferring particular properties to the bricks and shapes.
Max Service Temperature:
The temperature is based on the product being heated on one face only in a clean atmosphere.Heating on more than one face,mechanical load or the presence of corrosive dust,certain gases or slags will cause the maximum service tempetarure to alter.
Reversible Thermal Expansion:
This test is done as per IS 1528(part 19): 1991: DIN 51045
Chemical Analysis:
Carries out according to IS 1527 - 1972/ASTM C573 - 1981/ XRF- PW1480.
Apparentr porosity:Determined according to IS 1528 (PART-8) 1973/ASTM C20-1997/DIN 51065
Bulk Density : Determined according to IS 1528 (PART-8) 1973/ASTM C20-1997/DIN 51065
Cold Crushing Strength:Carried out according to IS 1528(PART-4) 1974/ASTM C133-1997/DIN 51056 (PART-1)
Pyrometric Cone Equipment : This test is done as per IS 1528 (PART-1) 1980/ASTM C24-89(1994)
Refractoriness Under Load : Determined according to IS 1528 (PART-2) 1974/ DIN 51053
Permanent Linear Change : Determined according to IS 1528 (PART-6) 1974/ASTM C210-95,C113-93.
Thermal Conductivity : Determined as per water calormetric.
Specification For Shaped Bricks:
  • The data related to machine moulded standard bricks only.
  • For shaped items,specification will be same as standard bricks except the following variations.
    BD will be lower by 0.10 gm/cc.,AP hugher by 2%,CGS lower by 100 kg/cm2 and RUL lower by 100 20* C from the specification values of standrand bricks mentioned in data sheet.
    • Product
    IS-7
    IS-6
    IS-8
    Pari-40
    Product type
    25% Alumina Bricks
    30% Alumina Bricks
    35% Alumina Bricks.
    30% Alumina Bricks
    Nature of Bond
    Ceramic
    Ceramic
    Ceramic
    Ceramic
    Shaping
    Dry pressed
    Dry pressed
    Dry pressed
    Dry pressed
    General Properties
    Raw Material Base
    Brick Grog
    Calcine Clay
    Brick Grog
    Brick Grog
    Max.Service Temp.
    1350*C
    1350*C
    1350*C
    1400*C
    Reversible Therm. Exp.
    -
    -
    -
    55% at 1000*C
    Chemical Analysis
    Al2O3
    25.00min
    30.00min
    35.00 min
    40.00 min
    Fe2O3
    3.00 max
    3.00 max
    3.00 max
    3.00 max
    Physical Properties
    Bulk Density g/cc
    2.10
    2.10
    2.20
    2.20 min
    Apparent Porosity %
    22 max
    22max
    22 max
    22 max
    Cold Crushing Strength
    300 min
    350 min
    350 min
    350 min
    Thermal Properties
    Refractoriness,Orton / *C
    29/1659 min
    30/1665 min
    30/1665 min
    32/1717 min
    RUL Ta*Cat 2 Kg/Cm2 load
    1350 min
    1350 min
    1350 min
    1400 min
    Thermal Conductivity
    at 800*C HF
    0.78
    0.82
    0.87
    0.89
    Size-Tolerance
    +1.5% or + 2mm
    +1.5% or + 2mm
    +1.5% or + 2mm
    +1.5% or + 2mm
